Semi-Automatic Ab Glue Aluminum Tube Filling Sealing Machine
Model:LFW-QJ-013
Product Description:
The machine was used for filling and sealing aluminum tube,with unique design concept.The whole sealing process goes smoothly and print beautifully.It's the ideal equipment for pharmaceutical, chemical, food, chemical industry.
Application:
The aluminum tube filling and sealing machine suitable for ointment, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste and other liquid or paste material.
Packing Examples: ointment, adhesive, AB glue, epoxy glue, skin cream, hair dye, shoe polish, toothpaste and other liquid or paste-like materials filling and sealing.
Filling container: Aluminum tube, various metal spft tube.
Optional Supporting Devices: three-dimensional packaging machine, cartoning machine, sealing and cutting machine, heat shrinking machine, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
Voltage (V/Hz) | AC 220V/50HZ 110V/60HZ | |||
Power | 1.2KW | |||
Gas source | 0.6-0.8(MPa) | |||
Tube mateial | Aluminum | |||
Tube diameter | 10-55mm（Can be customized） | |||
Tube length | 20-260mm（Can be customized） | |||
Gas consumption | 0.3(m³/min) | |||
Measuring accuracy | ±0.5~1% | |||
Machine material | Stainless steel | |||
Capacity | 25-30(pcs/min) | |||
Outline dimension | 1200L×720W×1300Hmm | |||
1.MT-6A is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meet GMP requirement. PLC controller and color touch screen are applied and made it possible for programmable control of the machine.
2.It can perform the filling for ointment, cream jellies or viscosity material, sealing or tail folding, batch number embossing (include manufacture date) automatically.
3.It has automatic tube positioning and identify function. It automaticly identify front and back side by the color mark.
4.The filling volume is adjustable on touch screen. It can fill 5-50ml etc liquid or sticky products.
5.It can print date or batch number as required. The number of letter can be set as required.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
