Automatic Syrup Bottle Filling And Capping Lines

Automatic Syrup Bottle Filling And Capping Lines

Application:

Automatic syrup bottle filling and capping machine(LFH-TJ-4), it is suitable for filling liquids and pastes of any fluidity in medicine, food, cosmetics and other industries.

Examples: syrup, oral liquid, sauce, shampoo, fruit juice, etc.

Packaging Type: Bottles, Cans, Tins, Barrel, Capsule, Cartons, Stand-up Pouch

Packaging Material: Glass, Metal, Paper, Plastic, Wood, Other

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Packaging Samples:

Full Automatic Syrup Bottle Filling And Capping Machine


Parameters:

ModelLFH-TJ-4
Filling Range50-1000ml (customizable)
Filling Speed

<15-25 bottles/min

(refers to the range of 100-500ml)

Measurement

Accuracy

±1%
Control systemPLC

Total production

line power

5.5KW
Power supply220V、50Hz
Airconsumption0.6-0.8m³/min
Equipment material
304

Description of main

packaging process

Unscramble bottles → Filling → Vibration plate upper cap → Four-wheel screw cap


Feature:

1. This production line adopts automation technology, imported PLC, imported inspection light eye, frequency converter and other electrical appliances, pneumatic components. It has the characteristics of high efficiency, intelligence, wide adaptability, good stability, etc., and is well received by users;

2. This line uses automatic bottle feeding, 4-head servo piston filling machine, vibrating plate automatic capping, and four-wheel capping machine to form an automated production line;

3. The filling machine uses food-specific hoses and does not contain plasticizers, which is suitable for medicine, food and other industries;

4. The piston cylinder of the filling machine adopts grinding and wear-resistant metering cylinder, which can automatically compensate the piston seal for long life;

5. The production line has stable operation, low noise, convenient maintenance, and fully meets the requirements of GMP certification, and is widely used in medicine, food, cosmetics and other industries;

6. The whole machine is made of corrosion-resistant stainless steel, which is easy to clean and disinfect, and meets the national regulations and requirements on food machinery and food hygiene;

7. Imported PLC and 7-inch touch screen man-machine interface, production parameterized control, simple operation;

8. Different improvements can be made according to the different requirements of customers, and can be made into equipment that fully meets the needs of customers. The plexiglass cover of the whole machine is designed to prevent impurities from entering the filling material, which is safe and hygienic.
