Semi Automatic Cream Lotion Glue Plastic Tube Filling And Sealing Machinery Machine
Model: LFF-GFW-00
Application:
Suitable for plastic tube and laminated tube filling and sealing, widely used in daily chemical products, medical products, food, chemicals, cosmetics, glue, and so on industries.
Application:
Semi Automatic Cream Lotion Glue Plastic Tube Filling And Sealing Machine(LFF-GFW-00), Commonly used in the filling and sealing of plastic tubes, and composite tubes in cosmetics, pharmaceutical, food, glue and other industries.
Examples:
Plasters, creams, glues, conditioners, body washes, skin care products, sauces, peanut butter, jams, creams, lotions, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
Model | LFF-GFW-00 |
| Application | Plastic tube, Composite tube |
| Tube Diameter | Φ10- Φ45mm |
| Tube Length | 50-150mm (customize) |
| Filling Volume | 5-300ml/pcs (adjustable) |
| Filling Accuracy | ≤±0.5% |
| Speed | 3-120r/min |
| Production Capacity | 20-36pcs/min |
| Compressed Air | 0.55-0.65mpa |
| Main Motor Power | 2.5kw (380V/220V/50Hz) |
| Dimension | 1100*850*1600mm |
| Weight | 550kg |
1.Using PLC control, it can fill liquids and high-viscosity liquids.
2.Automatically seal the tail, and can code the production date.
3.Commonly used in the filling and sealing of aluminum tubes, plastic tubes, and composite tubes in the cosmetics, pharmaceutical, food, adhesive and other industries.
4.The sealing machine can quickly seal the bag during operation and perform fast and accurate cutting, which can meet the needs of high-speed production lines.
5.All parts of the machine contacting materials are made of stainless steel SUS304;
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
