Automatic Horizontal Coffee Bean Premade Pouch Doypack Weighing Packing Machine
Model: LDSP-210
With wide application and a high degree of automation, it can meet the packaging needs of various types of products.
Application:
Suitable to use in packing high accuracy and easily fragile material. Such as coffee beans, dry food, nuts, pet food, puffy food, chips, jelly, candy, pistachio nuts, beef jerky, pasta, cotton candy, french fries, rice, small hardware, etc.
Application:
Suitable to use in packing high accuracy and easily fragile material. Such as coffee beans, dry food, nuts, pet food, puffy food, chips, jelly, candy, pistachio nuts, beef jerky, pasta, cotton candy, french fries, rice, small hardware, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
| Type | LDSP-160 | LDSP-160Y | LDSP-210 | LDSP-260 |
| Bag Type | 3-side, 4-side sealing bag, stand-up bag, handbag, spout bag, zipper bag, compound bag, etc. | |||
| Bag Size | 110-230mm*80-160mm(L*W) | 70-100mm*110-230(L*W) | 100-210mm/110-320mm(L*W) | 100-260mm/110-320mm(L*W) |
| Filling Range | 10g-100g | 10g-100g | 10g-1kg | 10g-3kg |
| Packing Speed | 20-45 bags/min(speed is determined by the product filling quantity) | 25-50 bags/min(speed is determined by the product filling quantity) | 20-50 bags/min (speed is determined by the product filling quantity) | 20-50 bags/min (speed is determined by the product filling quantity) |
| Machine weight | 800KG | 800KG | 900KG | 1000KG |
| Total Power | 2.0KW | 2.0KW | 2.0KW | 2.0KW |
| Work Flow | 1. Giving bag, 2. Pick up the bag(coding), 3. Open the bag up and down, 4. Filling, 5. Heating sealing, 6. Output of product | |||
| Dimensions | 1750mm*1285mm*1360mm(L*W*H) | 2140mm*1366mm*1360mm(L*W*H) | 2140mm*1366mm*1360mm(L*W*H) | |
| Collocation | Screw metering, screw elevator | |||
1. Horizontal doypack machine with fast speed but compact design.
2. 10 heads weigher with high weighing precision and anti-dust enclosure.
3. Vertical bag magazine station.
4. Ribbon coding.
5. Timing hopper to increase the weighing speed.
6. Vibrator plate.
7. Reliable quality electrical component.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
