Multi Track Fine Granule Mixed Spice 3/4 Side Sealing Sachet Packing Machine
Model: LD-480G/ 720G/ 960G
Advantage:
This machine is applicable for dosing fine particle products and sealing in form of 3/ 4 side sealed sachet, It can be expanded to 12 lanes at most. include the sachet forming, product dosing, filling and sachet sealing processes, with single cutting or string sachet cutting.
● This machine is applicable for dosing fine particle products and sealing in form of 3/ 4 side sealed sachet, It can be expanded to 12 lanes at most. include the sachet forming, product dosing, filling and sachet sealing processes, with single cutting or string sachet cutting.
● Multi Track Fine Particles Mixed Spice 3/4 Side Sealing Sachet Packing Machine, it is suitable for the 3/ 4 sides sealing packing of many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
| Model | LD480G | LD720G | LD960G |
| Track Number | 4~6Track | 4~10Track | 4~12Track |
| Filling Method | 1.Volumetric cup; 2.Weigher | ||
| Capacity | Max.35 cycle/min | ||
| Sachet Size | L:45--120mm; W:35-60mm | L:45--120mm; W:35-90mm | L:45--120mm; W:35-120mm |
| Film Width & Thickness | Max.480mm; 0.07-0.1mm | Max.720mm; 0.07-0.1mm | Max.960mm; 0.07-0.1mm |
| Sealing Type | 3/ 4 sides sealing | 3/ 4 sides sealing | 3/4 sides sealing |
| Cutting Type | 1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting | ||
| Air & Power | 0.8 mpa 0.8m³/min; 2.8kw | 0.8 mpa 0.8m³/min; 4.1kw | 0.8 mpa 0.8m³/min; 5.5kw |
| DIM & WT | 950*1470*1750mm; 300kg | 1153*1654*1750mm; 400kg | 1415*1686*2130mm; 500kg |
1. Multilanes design to improve packing speed. We have 4-16 lanes available now.
2. The complete set of electrical appliances and control system uses famous brand electronic components such as Schneider PLC, Semens touch screen, Sick Sensor, FESTO cylinder.
3. The machine frame material is SUS304 stainless steel to ensure service life.
4. Machine will automatically complete all packaging processes from measuring, feeding, filling, printing, finished bag.
5. The vertical design makes the machine can be installed easier and with smaller dimension to fit flexible for various workshops.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
